The all-new Marin Alpine Trail series is our boldest and most capable line of enduro bikes ever, built upon our most advanced, most adjustable frames to date.
Series 4 aluminum MultiTrac 2 LT frames feature mixed 29”/27.5” wheels, 170mm front and 160mm rear travel, and the utmost in adjustability. Riders can alter the head tube angle and bottom bracket/chainstay length, as well as run 29” rear wheels if desired. “Bear Box” downtube storage includes a zippered nylon bag to house trail essentials, and a 34.9mm seatpost increases strength and is compatible with the latest dropper posts.
While the Marin Alpine Trail 1 is the starting point in the three-model lineup, we didn’t make any concessions regarding the spec. High-performance Fox suspension keeps you in control, while a Shimano Deore 12-speed drivetrain transmits your power to the wheel. TRP’s Slate Evo 4-piston brakes feature 203mm rotors, keeping all that speed in check in a powerful, fade-free manner.
Sunset Cycles offers the 2024 Marin Alpine Trail 1 enduro mountain bike with up to 36 months 0% finance and free delivery.
The 2024 Marin ALPINE TRAIL range: Alpine Trail 1 | Alpine Trail Carbon 1 | Alpine Trail Carbon 2 | Alpine Trail XR | Alpine Trail XR AXS
| Frame | All New Series 4 6061 Aluminum, 29” Wheels, 160mm Travel MultiTrac LT Suspension Platform, Integrated Downtube Storage, Adjustable Headset & CS Length/BB Height, Full Internal Cable Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs |
| Fork | Fox 36 Rhythm, 170mm Travel, 29", Grip Damper, 110x10 Kabolt, 44mm Offset |
| Rear Shock | Fox Float Performance, 205x65, 30xM8 Lower Hardware, Custom Tune |
| Rims | Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible |
| Hub Rear | Shimano HB-TC500, 148x12mm, Micro Spline Freehub Body |
| Hub Front | Shimano FH-TC500, 110x15mm |
| Spokes | 14g Black Stainless Steel |
| Tires | Vee Tire Co. Snap WCE, 29x2.6" Front 27.5x2.6" Rear, Top 40 Compound, Enduro Core, 90 TPI, Tubeless Compatible |
| Derailleur Rear | Shimano Deore, 12-Speed, SGS |
| Shift Lever | Shimano Deore, 12-Speed, SL-6100-IR |
| Crankset | FSA Comet Heavy Duty, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing |
| Bottom Bracket | FSA MegaExo 73mm BSA |
| Chain | KMC X-12 Silver and Black |
| Cassette | Shimano, Deore M6100 12-Speed, 10-51T |
| Brakes Front | TRP Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor |
| Brakes Rear | TRP Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor |
| Brake Levers | TRP Slate EVO Hydraulic, I-Spec EV Compatible |
| Handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
| Stem | Marin 3D Forged Alloy, 35mm |
| Grips | Marin Grizzly Lock-On |
| Headset | FSA Custom, Adjustable HTA Design |
| Seatpost | TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm |
| Saddle | Marin Speed Concept |
| Pedals | - |
| Extras | Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head Downtube Storage Bag |
| Frame Size | Rider Height Guidance* |
| Small | 5'3" to 5'6" |
| Medium | 5'6" to 5'10" |
| Large | 5'10" to 6'2" |
| X Large | 6'2" to 6'4" |
| *This is for guidance only. You may be taller or shorter, it doesn't mean our bikes will not fit you. The best way to determine the correct bike size for you is to try one. Please contact us if you are in any doubt about the correct bike size for you. | |
